How to properly store the anilox roller and the anilox roller

(1)The storage box of the anilox roller should be stored in a dry place in the room to prevent damage by damp, rain or direct exposure.

(2)In the replacement of ceramic roller to protect the ceramic roller surface, to prevent collision damage. After the work of the ceramic anilox roller must also be timely and thoroughly clean, do not store clean and not dry ceramic anilox roller, storage should be made of natural fiber packaging foil wrapped roller, and then put into the storage box.

(3) The ceramic anilox roller which is not stored in the box shall be fixed on a special storage bracket. It is strictly prohibited to place the roller surface on the ground with an inclined position, or it may easily cause damage to the ceramic coating on the surface of the ceramic anilox roller.

Anilox roll movement: Do not use tape directly fixed on the ceramic anilox roller of roller to roll lifting movement, in order to avoid ascends will drop roller broken, is the proper way to move the roller to tape or other support fixed on both ends of the roller shaft head, and avoid contact with roller edge or other parts of the ceramic layer coating.

Usage of anilox roller :

(1)Ceramic anilox roller must be carefully cleaned before use, and carefully check the surface of the anilox hole to ensure no oil, no dust.

(2)Every time after the printing must be thoroughly clean ceramic anilox roller roller surface, avoid the light of the residual oil residue in the bottom of the mesh dry solid and jams mesh, such as residual ink once dry solid in the bottom of the mesh is difficult to effectively clean, and piling up, reduce the effective volume mesh, release a quantity to reduce light oil, thus affecting printing quality.

(3)Remove dust from the surface of the printed matter and keep the printing area clean before printing.

(4)Do not dry ceramic anilox roller and squeegee rubber roller or squeegee pressure rotation, so as to avoid damage to the surface of the roller body.

(5)In the ink tank placed in the magnetic filter clear metal impurities, metal impurities to avoid scratches ceramic roller surface.

(6)Every time the squeegee is updated, the pressure needs to be reset, and the wrong pressure setting will cause the blade debris to damage the surface of the ceramic anilox roller.

(7)Stop using the scraper that has exceeded the maximum wear level, establish a daily process to monitor the change of the scraper wear, and stably control the wear level of the scraper to avoid damage to the ceramic anilox roller.

(8)The ceramic anilox roll surface is kept parallel with the scraper at all times, and the vertical and horizontal degrees of the drum and the scraper are inspected and calibrated every 15 days.

(9)Clean ink, dust and recovery of the printing unit on the machine after printing.

(10)With the correct mesh depth and opening ratio, the correct ratio means a smoother surface and slower blade wear, while making it easier to clean the mesh.

Maintenance techniques for anilox rolls:

(1)Frequent use of mesh microscopy to detect the mesh of ceramic anilox rolls. If wear and blockage are found, measures should be taken in a timely manner.

(2)Do not over pressurize the squeegee for more color to increase the wear of the ceramic anilox roller and the squeegee.

(3) Refuse to use inferior inks containing filler impurities to avoid damage to the ceramic anilox roller and the doctor blade or the scraper rubber roller.
