CuZn40Ni10
INTRODUCTION
CuZn40Ni10 provides higher mechanical properties making this suitable for build-up and overlay applications such as gear teeth, bearings, and valve seats. The silicon addition helps prevent fuming (Zinc vaporization). The weld deposits have a very high tensile strength, good ductility and excellent corrosion resistance. These are used to braze weld steel and cast iron. The deposit provides a good color match to these metals.
CHEMICAL COMPOSITION
AWS Code |
Alloy |
Cu% |
Si% |
Ni% | Zn% |
---|---|---|---|---|---|
Cu 7730 |
CuZn40Ni10 | 49 |
0.15 |
10 |
Rest |
Typical Physical Properties
Solids Temperature | Density | Elongation | Liquids Temperature | Tensile Strength | Brinell Hardness |
---|---|---|---|---|---|
890°C | 8.4kg/dm3 | 25% | 935°C | 385N/mm2 | 120HB |
Advantage:
Resonable price, in stock for regular sizes, short lead time
International production technology, quality guaranteed
100% replacement / refund (delivery included) for problematic items
Spray process
Arc Spray
Arc spraying is the use of electric arc burning in two consecutive fed between the wires to melt the metal, with a high velocity gas stream molten metal atomization, and the atomization of the sprayed metal particles so that they accelerate the work to form a coating technology .
Flame Spray
The use of a flame as the heat source, the metal and non-heated to a molten state, forming a mist flow in the state of high-speed air jet to the substrate, the injection of the molten minute particles impact upon the substrate above, plastic deformation, into a sheet shape superimposed sedimentary layers.
Application
Gear teeth, bearings, and valve seats
Packing and shipping
STANDARD SIZE&PACKING
Diameter |
Dimension Tolerance |
Packing |
Wire Weight |
---|---|---|---|
1/16"(1.6mm) |
+0/-0.05 |
D 300 Spool |
15kgs(33 lbs)/spool |
2.0mm |
+0/-0.05 |
D 300 Spool |
15kgs(33 lbs)/spool |
1/8"(3.17mm) |
+0/-0.05 |
Coil Form |
20-400kgs/coil |
Other sizes can be produced based on customers’ requirement.
Label
Brand, Neutral or Customized
Delivery
Courier/Air/Sea
Normally we keep stock of 1.6mm, can deliver in 1-3 days.
For mass order, delivery time is depends on the quantity.
Please Feel free to give your inquiry in the form below.We will reply you in 24 hours.
